Foxconn H61MXV Series User Manual

4
57
1-2 Local Update - Backup
ThispagecanbackupyoursystemBIOS.Youcanclick“Backup”,andkeyinalename,then
click“Save”tonishthebackupoperation.Theextensionofthisbackupleis".BIN"forAward
BIOSand".ROM"forAMIBIOS.Defaultdirectoryis"C:\Desktop\MyDocuments"inWindowsXP
and"Documents"inVista.Makesureyoucanrememberthelenametogetherwiththedirectory
which it is stored, prevented that you may need them to recover your BIOS later.
1-3 Local Update - Update
ThispagehelpsyoutoupdateyourBIOSfromalocalle.Afterclick“Update”,Analertmessage
willbedisplayedtoensureifyoureallywanttocontinue,click“Yes”toconrm.Asetupwizard
willguideyoutoloadalocalBIOSletonishtheoperation.Youmustrememberfromwhich
directorytoloadyournewBIOSle(withanextensionof".BIN"forAwardBIOS,".ROM"forAMI
BIOS) before the setup wizard starts.
KeyinaBIOSname
Click here
FOX LiveUpdate can automatically backup old BIOS before update. This feature can be
enabledinthe"Congure-System"setup.Pleasereferto"Congure-System"section
formoredetail.ThedefaultbackupdirectoryisC:\LiveUpdate_Temp,butthebackup
lenamewillbeautomaticallygenerated.Itishardtonditoutfromabackupdirectory,
andwerecommendyouusingExplorertocheckdate/timemessageofthisbackuple
tonditoutandwriteitsnamedowntorememberit.
C
A
U
T
I
O
N
!

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
