4.Afterexitingfrom"RAID Level",itgoesdirectlyto"Stripe Size"item.Becauseall
four disks are selected for RAID10, so there is no need to go to Disks option.
5.UseUporDownarrowkeytoselectthedesiredstripsizewhenentering“Strip
Size”menu.Thedefaultvalueis64K.
6. In “Capacity” item, use the default value, and press <Enter>. The default value is
twicethesmallestharddisksize,thatis,74.5GB*2=149GB.
7. Select “Create Volume” and press <Enter>. A warning message will appear :
Press <Y> to create the volume and return to the main menu.
WARNING:ALLDATAONSELECTEDDISKSWILLBELOST.
Are you sure you want to create this volume ? (Y/N) :
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
The following are typical values:
     RAID0-128KB
     RAID10-64KB
     RAID5-64KB
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
TryRAID10
RAID10(RAID0+1)
Select Disks
128K
149.1GB
N/A
Create Volume
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
[ HELP ]
64KB
[ CREATE VOLUME MENU ]
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2.DeleteRAIDVolume  4.RecoverVolumeOptions
   5.Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID10  RAID10(0+1)64KB 149.1GB
Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Member Disk(0)
1 ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
 2 SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Member Disk(0)
3 ST380815AS 5RW1CA37  74.5GB Member Disk(0)
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
