5
77
8. In “Create Volume” item, press <Enter>.
A warning message will appear :
9.Press<Y>tocreatethevolumeandreturntothemainmenu,a150GBRAID0system
isnormallycongured.
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume ? (Y/N) :
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
Press ENTER to create the specified volume.
TryRAID0
RAID0(Stripe)
Select Disks
128KB
150GB
N/A
Create Volume
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
[ CREATE VOLUME MENU ]
Create Volume
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ HELP ]
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2.DeleteRAIDVolume  4.RecoverVolumeOptions
   5.Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID0 RAID0(Stripe) 128KB 150.0GB0 TryRAID0  RAID0(Stripe)128KB150.0GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 Hitachi HDS72161 PVF904�21G2J�M 149.0GBHitachiHDS72161 PVF904�21G2J�M 149.0GB PVF904�21G2J�M 149.0GB MemberDisk(0)
1 ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2 SAMSUNG HD161HJ  S0V3J9APA30524 149.0GBS0V3J9APA30524 149.0GB 149.0GB MemberDisk(0)
3 ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
