Appendix – Graphical symbols, safety signs and product safety labels
55
Interface for connection to a personal computer (PC).
USB port.
Interface for connection to external USB devices.
Interface for connection to a local computer network (LAN).
CAN-BUS The CAN bus is a serial bus system.
The abbreviation CAN stands for Controller Area Network.
Interfaces for connecting system components.
Symbol for alternating voltage.
Indicates the type of the input voltage.
Symbol / Wiring symbol for a fuse.
This symbol always stays along with the details of the fuse used.
The plate contains important information for the fuse:
Caution: For continued protection against risk of fire, replace
only with same type and rating of fuse.
