Part No. 22958 Rev. P June 2017 - 34 - Fusion, Food & Beverage Cabinet
Cabinet Performance
COMBINED FOOD & BEVERAGE CABINETS - SPECIFICATIONS
Refrigerated
Section
Performance
Operating Temperature
Average Internal Humidity
Climatic Class 3 Test Conditions
+2° to +4°C
70% RH
25°C Ambient with 60% RH
Controller Settings
COMBINED FOOD & BEVERAGE CABINETS - SPECIFICATIONS
Application
Specific
Settings
The following table specifies the settings for the Dixell XR40CX Controller which
are specifically for this FPG cabinet.
XR40CX Settings
Parameter
Description
Setting
Unit / Range
Set
Set Point
-4
degC
Hy
Differential
3.5
degC
P3P
Third Probe Used
Y
n=no, Y=yes
AC
Anti Short Cycle Delay
0
Min
C0n
Comp On Time - Faulty Probe
4
Min
C0F
Comp Off Time - Faulty Probe
6
Min
dtE
Defrost Terminate Temp
6
degC
IdF
Interval Between Defrosts
2
Hrs
dFd
Display During Defrost
DEF
rt, it, Set, DEF
AP2
Probe For High Discharge Temp Alarm
P3
nP, P1, P2, P3, P4
AU2
High Discharge Temp Alarm Set Point
100
degC
AH2
High Discharge Temp Alarm Diff
25
degC
Ad2
High Discharge Temp Alarm delay
0
Min
dA2
High Discharge Alarm Delay At Start
0
Min
AC2
Comp Off For High Discharge Temp Alarm
Y(1)
n(0)=no, Y(1)=yes
