10 | Technical data
Power Quality Controller – PQC | Operating Manual | FRAKO
Category Single phase 3-phase
Type xxxxxx1-xx xxxxx3-xx
Type xxxxxx-4x
Prole switching
(T)
S0 pulse as per DIN 43864,
common earth with FRAKO Starkstrombus (Frakobus)
Interfaces:
Type xxxxxx-2x xxxxxx-3x xxxxxx-4x
Modbus RTU
interface
120 Ω terminating
resistor required at the
end of the bus system
Ethernet interface
(Modbus TCP, web
server)
100 Mbit/s
Ethernet standard
100BASE-T
FRAKO
Starkstrombus
(Frakobus)
RS-485, surge
impedance 120 Ω,
for connection to the
FRAKO Energy Man-
agement System
Outputs:
Category 12 output relays 6 output relays 6 output relays
Type 120xxxx-xx 060xxxx-xx 061xxxx-xx
Output relays
(outputs for
switching stages)
NO contact with common pole P;
AC - 14 250 V AC, maximum 3 A
or DC - 13 30 V DC, maximum 3 A,
mechanical service life 2 × 10
7
cycles,
electrical service life AC - 14 at 3 A:
1 × 10
5
cycles,
AC - 14 at 0.5 A: 2 × 10
6
cycles
AC-14 440 V AC,
max. 3 A
or DC-13 125 V DC,
max. 3 A, mechanical
service life
1 × 10
7
cycles, electri-
cal service life AC-14
at 3 A:1 × 10
5
cycles,
AC - 14
at 0.5 A: 2 × 10
6
cycles
Common supply conductor P to the output relays maximum 10 A;
Note: utilization category AC-14/DC-13 as per IEC 60947-5-1; for all
PQC types in areas where UL / CSA standards apply: 3 A 250 V AC
cosφ = 1 at 85 °C, 3 A 30 V DC L/R = 0 ms at 85 °C
