16 | Instrument description
Power Quality Controller – PQC | Operating Manual | FRAKO
4.2 Instrument versions
The PQC is available in various versions, identifiable by their type designation:
PQC xx x xxx x – x x Type designation
PQC
PQC
12
06
0
1
240
480
1
1
–
–
2
3
1
0
Example
Measurement inputs:
1 = Temperature (I/O extension)
Interface:
2 = Modbus RTU
3 = Ethernet
4 = FRAKO Starkstrombus (Frakobus)
Measurement inputs:
1 = single-phase
3 = 3-phase
Max. supply voltage:
240 V
480 V
Output relays:
0 = 250 V
1 = 440 V
Number of switching outputs:
12
06
4.3 User interface
The instrument is operated with the following keys located below the display:
Key
Action
PQC
overview
Select Select
Open
submenu
Display
information
Note
The keys are assigned different functions according to the particular menu.
These specific functions are described in the appropriate section.
