Description of the menu | 67
FRAKO | Operating Manual | Power Quality Controller – PQC
Menu Parameter Setting
Settings for
control prole 1
cosφ 0.92 ind
Parallel shift –1
Limitation 1
Switching delay 45 s
Phase L1
Active ON
Settings for
control prole 2
cosφ 1.0
Parallel shift 0
Limitation OFF
Switching delay 45 s
Phase L1
Active OFF
Settings for
control prole 3
cosφ 1
Parallel shift +1
Limitation OFF
Switching delay 45 s
Phase L1
Active OFF
Settings for
control prole 4
cosφ 0.92 ind
Parallel shift –1
Limitation OFF
Switching delay 45 s
Phase L1
Active OFF
Settings for
control prole 5
cosφ 0.96 cap
Parallel shift –1
Limitation OFF
Switching delay 45 s
Phase L1
Active OFF
Alarms (Section 6.3.4 “Alarms”)
Alarms Relay function NO (normally open)
cos φ alarm
Control band alarm OFF
Alarm relay ON
Display ON
Emergency trip OFF
