Franka Emika Panda - Ventilation and Derating; Ambient Conditions for Control

Franka Emika GmbH © October 2018
58
NOTICE
The Arm contains power electronic components and modules (electric drives,
CPUs, etc.) which heat up depending on the stress the device is subject to.
The Arm does not contain acve cooling systems, meaning that the produced
heat is given o via the Arm’s surface.
Therefore:
• make sure that the Arm is adequately venlated
• make sure the Arm is not exposed to direct sunlight
• make sure that the Arm is not painted, pasted up with something or enwrapped
When operang within the “extended temperature range”, the possibilies for
applicaon of the Arm may be limited (e.g. the speed or acceleraon may need
to be reduced), in order not to overheat the system.
Adequate venlaon
Derang

Permissible condions at site
of installaon
Site of installaon
• indoors, in enclosed buildings
• not exposed to direct sunlight
• no vibraons
• no magnec elds
Type of installaon
• device can be installed vercally and horizontally to the earth’s surface
• mounng in angle brackets e.g. under tables
• mounng in control cabinets (2U, 4HP)
Protecon class
• IP 20 (according to EN 60529:1991)
• IP 2x: protected against ingress of solid bodies with a dimeter
>=12.5mm
• IP x0: no protecon against water
Ambient medium
• air
• free from ammable substances (dust, gas, liquid)
• free from aggressive media
• free from corrosive substances
• free from “ying parts”
• free from spraying liquids
CORRECT SITE OF INSTALLATION
