16| USER MANUAL
WEIGHTS
Maximum Gross for Takeoff
1
13.6 kg (30.0 lbs)
Maximum Useful Load
2
9.1 kg (20.0 lbs)
Maximum Payload
3
6.8 kg (15.0 lbs)
Typical Standard Empty Weight: 4.5 kg (10.0 lbs)
SPECIFIC LOADINGS
Typical Specific Power
4
145 W/kg
Thrust Ratio at MTOW
1
1.85 : 1
1
At sea level, ISA.
2
Top and bottom mount. Includes batteries.
3
Payload weight top or bottom mount.
Battery weight not included and mounted
on opposite side from payload.
4
At MTOW, sea level, ISA.
