47| USER MANUAL
COMPASS CALIBRATION
For best results, it is recommended to perform manual compass calibrations away
from ferrous objects, buildings and vehicles. In addition, concrete can contain steel
rebar which may influence compass calibrations.
WARNING
Verify ALTA is disarmed prior to performing a compass calibration.
To ensure ALTA does not arm, set the Arm Enable Switch (if
available) to disable, and remove the Configuration Jumper.
NOTE
It is recommended to use two people to perform the
compass calibration as it requires handling and rotating
ALTA. Perform calibration without a payload attached.
NOTE
Ensure a microSD card is installed in the GPS/compass
module prior to performing compass calibration.
TO PERFORM A COMPASS CALIBRATION:
1. Secure a battery onto ALTA
2. Plug in the battery
3. Open the ALTA app
4. Select Configurations > More > Compass
5. Under Calibration, select Start Manual
6. Follow the on-screen instructions
