30| USER MANUAL
RADIO INSTALLATION
RADIO CONTROLLER RECEIVER
ALTA requires the installation of a radio control system. S.Bus, S.Bus2, DSM2,
DSMX, and PPM (including inverted PPM and Graupner) receiver types are
supported.
Additionally, ALTA supports radio receiver diversity using S.Bus, S.Bus2, DSM2 and
DSMX receivers. This means two receivers may be installed, and the SYNAPSE flight
controller will automatically use the receiver with the best signal quality. Using two
receivers requires the radio controller to be bound to both receivers.
Refer to the instructions provided with your radio controller to complete the binding
process. For Spektrum/JR radios, a receiver is required to bind the satellites to a
radio controller.
1. Locate the noted closeout panels used for receiver
installation (between booms 1 & 2 and 5 & 6)
2. Remove side closeout panel with radio wires using a 1.5mm hex driver
