15| USER MANUAL
SPECIFICATIONS
DIMENSIONS
DIAMETER (DOES NOT INCLUDE PROPS)
Unfolded Diameter 1126 mm
Folded Diameter 515 mm
Height to base of Toad In The Hole (TITH) 220 mm
POWERPLANT
Number of Motors 6
Motor Type Direct Drive 3-Phase PMAC Outrunner
Motor Model F45
Motor Max Continuous Power Output 350 W
Motor Max Instantaneous
Peak Power Output
950 W
Maximum RPM (flat rated) 6300 RPM
Equivalent Kv 384
Electronic Speed Controller Freefly Silent-Drive Sine Wave ESC
PROPELLERS
Material Carbon fiber with balsa core
Propeller Orientation (3) CW and (3) CCW Props
Propeller Type 18 × 6 Folding
BATTERY
Nominal Battery Voltage 6S / 22.2V
Maximum Battery Size 240 × 180 × 80 mm
Maximum Battery Quantity 2 Battery Packs (Parallel)
Battery Connectors 2× EC5 (Parallel)
Required Minimum Battery
Discharge Rating
Dual Pack: 200A / 400A Peak
Single Pack: 300A / 600A Peak
