53| USER MANUAL
TRANSMITTER
1. Mount FPV transmitter on the provided carbon fiber accessory mount plate.
2. Attach Accessory Mount to boom 5 with M3×8 flathead bolts.
3. Locate the appropriate FPV transmitter cable. The following cables are included:
a. ImmersionRC/Fat Shark (cable with two connectors)
b. Boscam/SkyZone (cable with one connector)
4. Remove the side closeout panel with the FPV
transmitter lead using the 1.5mm hex driver.
