56| USER MANUAL
Roll Marker
Basic
Adds small dash marks on the left
and right side of the artificial horizon
that indicate changes in roll
Horizon Adds marks to include a full horizon line
Ladder
Adds small marks on either side
of the artificial horizon ladder that
roll with ALTA roll movements
Pitch and
Roll Scaling
10, 20, 30, 40
Allows for scaling of the artificial
horizon markings to compensate for
FPV cameras of different field views
Pitch and
Intervals
10, 20, 30, 40
Sets the number of degrees
between pitch markings when the
artificial horizon ladder is used
OTHER COMPONENTS
The following components can be turned on or off. There are no other options
associated with these components.
NAME DESCRIPTION
Compass Arrow Displays an arrow that points in the direction of north
Home Arrow
Displays an arrow that points in the
direction of the home point
Vario Bar
Displays a bar on the right of the screen that scales
with vertical speed. The bar will increase in length
up to indicate a climb, or down to indicate a descent
Forward Velocity
Displays a bar on the left of the screen that scales
with the forward/rearward velocity component
The bar will extend up to indicate forward velocity,
or down to indicate a rearward velocity
Sideslip
Displays a bar on the bottom of the screen that
scales with the side-to-side velocity component
The bar will extend left to indicate leftward
velocity, or right to indicate rightward velocity
