User Manual and Reference Guide
LUM0024AB Rev A
Enter the following port settings for a proper connection:
Port Setting Select
Bits per second 19200
Data bits 8
Parity None
Stop bits 1
Flow control None
7. After selecting the option for each setting, click OK.
The following HyperTerminal dialog box displays:
8. From the File menu, select Save to save the HyperTerminal connection settings
11
