is used for removal. During installation, the vent
cap is to be hand-tightened only, not tightened
with a wrench.
4.
Remove the filter cover, filter cover seal and
spring. Retain them for later assembly.
5.
Remove the filter element and dispose of it
properly.
NOTE: Remove the rubber grommet from the
stud.
6.
Install the standard engine spin-on filter (included
in the emergency kit) on the threaded stud.
7.
Install the filter cover, filter cover seal, and
spring, as removed.
f47041705/16/2017
1
2
4
6
7
5
8
3
9
11
10
1. Filter Collar
2. Filter Vent
3. Filter Vent Seal
4. Filter Cover
5. Filter Cover Seal
6. Spring
7. Filter Element
8. Threaded Stud
9. Fuel Port
10. Drain
11. Bottom Plate Collar
Fig. 23.2, Davco Model 382 Fuel/Water Separator
02/16/2009
f470277
VENT CAP
FOR REMOVAL OF TOP COLLAR ONLY
Fig. 23.3, DAVCO Collar Wrench
In an Emergency
23.2
