Chapter 3: Design and function of the individual components of the device
Fresenius Kabi CompoSeal Universal OP-EN 6/07.13 7
3 Design and function of the individual
components of the device
3.1 CompoSeal Universal
Legend
1 Handle
2 Label UL approval (120 V sealing system only)
3 Label connector for hand sealer
4 Connector for hand sealer
5 On/Off switch
6 Connector for power cable
7 Voltage indicator
8 Sealing head
Sealing head cover removable for cleaning purposes
1
9
2
3
4
5 6 7
8
Upper red progress LED
Lower red progress LED
Lower green progress LED
Power on LED
Time limit LED
Spark LED
