Chapter 3: Design and function of the individual components of the device
8 Fresenius Kabi CompoSeal Universal OP-EN 6/07.13
9 Indicator foil
The progress LEDs indicate the sealing progress and the
end of the sealing process.
The power on LED indicates whether the device is turned
on and ready for operation.
The time limit LED (limitation of the sealing time) indicates
whether an incorrect sealing process has taken place.
The spark LED (spark detector) indicates whether
sparking has occurred during a sealing process.
3.2 Hand sealer (optional)
Legend
1 Sealing electrodes
2 Sealing indicator
stops lighting on completion of the sealing process
3 Exchangeable cable
2
1
3
