QUANTUM™ HD UNITY SYSTEM CONTROLLER
MAINTENANCE
090.670-M (APR 2020)
Page 39
Digital Board Settings
Communications settings
Use the following table when conguring the Quantum™ for external communications.
Table 11: Communications settings
J5
in 120 ohm long communications line termination.
out* No termination.
J7
in RS-422/485 transmit pull-up for long communications lines.
out* No pull-up.
J8
in RS-422 transmit pull-up for long communications lines.
out* No pull-up.
J9
in RS-422/485 receive pull-down for long communications lines.
out* No pull-down.
J10
in RS-422 receive pull-down for long communications lines.
out* No pull-down.
* = standard setting
Dipswitch settings
Use the following dipswitch setting tables to set the remote evaporator panel digital board addresses. The 10 remote panels
are equally split between two comm ports. Group A (zones 1-15) are on Comm. 4. Group B (zones 16-30) are on Comm. 3.
See and study the diagram on the next page to determine the correct board conguration.
Table 12: Evaporator remote panel group A / Comm
4 (zones 1-15)
I/O
Panel
Digital
Board #
SW1 SW2 SW3 SW4 SW5 SW6
1
1 On On On On Off On
6 Off On Off On Off On
2
2 Off On On On Off On
7 On Off Off On Off On
3
3 On Off On On Off On
8 Off Off Off On Off On
4
4 Off Off On On Off On
9 On On On Off Off On
5
5 On On Off On Off On
10 Off On On Off Off On
Table 15: Evaporator remote panel group B / Comm
3 (zones 16-30)
I/O
Panel
Digital
Board #
SW1 SW2 SW3 SW4 SW5 SW6
6
1 On On On On Off On
6 Off On Off On Off On
7
2 Off On On On Off On
7 On Off Off On Off On
8
3 On Off On On Off On
8 Off Off Off On Off On
9
4 Off Off On On Off On
9 On On On Off Off On
10
5 On On Off On Off On
10 Off On On Off Off On
Use the following Condenser/Vessel and Engine Room dipswitch setting tables to set digital board addresses. Refer to and
study the diagrams on the next page to determine the correct board conguration.
Table 13: Condenser digital board dipswitch settings
Digital
Board #
SW1 SW2 SW3 SW4 SW5 SW6
1 On On On On Off On
2 Off On On On Off On
Table 14 Vessel digital board dipswitch settings
Digital
Board #
SW1 SW2 SW3 SW4 SW5 SW6
4 Off Off On On Off On
5 On On Off On Off On
6 Off On Off On Off On
Table 16: Engine room digital board
dipswitch settings
Digital
Board #
SW1 SW2 SW3 SW4 SW5 SW6
1 On On On On Off On
