Frick QUANTUM HD UNITY User Manual

QUANTUM™ HD UNITY SYSTEM CONTROLLER
MAINTENANCE
090.670-M (APR 2020)
Page 52
Service – Diagnostics
Diagnostics: The Service page is broken into 4 basic
categories: Diagnostics, Communications, Software, and
Screen Calibration.
The “Diagnostics” page shown above provides the follow-
ing features:
Show Ethernet Port Settings – provides all pertinent eth-
ernet port information for the IP address of the controller
being viewed.
Ping The Below IP Address – Conrm connectivity of a
known IP address and the network.
Download System Data – Download all system operating
data to a USB thumb-drive.
Check I/O Integrity – The I/O Integrity check determines
if there are any I/O conguration conicts where a board
and channel are congured in two or more places. This
check is also done every time a board and channel are
congured.
