Frick QUANTUM HD UNITY User Manual

QUANTUM™ HD UNITY SYSTEM CONTROLLER
MAINTENANCE
090.670-M (APR 2020)
Page 61
Part Number Description
Analog board
640C0062G01 Analog board replacement (use existing board to congure new board)
640C0062G12 Analog board eld installation/upgrade kit (use maintenance manual to properly congure
the new board for the application)
Digital boards
640C0024G71 Digital board eld installation/upgrade kit (use maintenance manual to properly congure the
new board for the application)
640C0024G01 Digital board replacement (use existing board as a reference to congure new board)
111Q0281061 Output module, 24 VAC to 280 VAC
333Q0000116 Input module, 120 VAC
333Q0000789 Input module, 220 VAC
333Q0001326 Fuse, 5 amp, 250 V
Power supplies
639B0115H01 5 VDC power supply, 25 W
639D0296H01 12 VDC power supply, 72 W
639D0296H02 24 VDC power supply, 72 W (main unity controller)
639B0115H03 24 VDC power supply, 48 W (remote evaporator I/O panel)
Processor boards*
649C1170G01 Q6 processor board
649C1171G11 Q5 to Q6 Quantum HD Unity condenser/vessel upgrade kit
649C1171G21 Q5 to Q6 Quantum HD Unity evaporator upgrade kit
649C1171G31 Q5 to Q6 Quantum HD Unity engine room upgrade kit
Interface boards
639B0116H01 Interface board (used with Q5 processor board only)
Display/Touchscreen
639D0199H01 Display (indoor)
649D6101G01 Touchscreen overlay (FRICK)
HOA modules
643D0072G01 Module #1 (condenser)
643D0072G02 Module #2 (condenser)
SECTION 8
-
REPLACEMENT PARTS
REPLACEMENT PARTS LIST
