Friedrich VRP7k - VRP System Specifications; Cooling and Heat Pump Performance Data

13 PB
SPECIFICATIONS
Cooling Performance
Figure 201
Model VRP7K / VRP7R
Cooling Performance Data (Cooling Standards: 95°F DB/75°F
WB outdoor, 80°F DB/67°F WB indoor)
Voltage 230/208 265
Cooling Btu (Rated) 7,000
Cooling Btu (Min. – Max) 3,300‑9,000
Outdoor Operating Range (°F) 55 – 115
Power (W) 593
SEER 15.5
EER 118
Sensible Heat Ratio 0.76
Cooling Amps 2.9
Heat Pump Performance Data
Heating Btu (Rated @ 47° F) 7,400
Heating Btu (Min. – Max.) 3,000‑8,800
Heat Pump Outdoor Operating
Range (°F)*
0 – 70
COP (Rated @ 47° F) 3.4
HSPF 8.5
Heating Power (W) 650
Heating Amps 3.2 3.2
