COMPONENT TESTING
Heating Elements
Part Number Coil Resistance Thermal Disc Limiter Thernal Disc Fuse specs
80102291 13.68 Ohms +‑ 5% Open 155°F Close 125°F 08‑2834‑09
Open 200°F
3.4 kw 230v
80102290 18.61 Ohms +‑ 5% Open 155°F Close 125°F 08‑2834‑09
Open 200°F
2.5 kw 230v
80102295 24.71 Ohms +‑5% Open 155°F Close 125°F 08‑2834‑09
Open 200°F
2.5 kw 265v
80102296 18.17 Ohms +‑5% Open 155°F Close 125°F 08‑2834‑09
Open 200°F
3.4 kw 265v
