27 PB
INSTALLATION
Exterior Wall Opening Dimensions
10
Exterior Wall Opening Dimensions
Exterior Wall Rough Opening Dimensions
Unit Width Heigth
VPAWP1-* 24 5/8" 30 7/8"
NOTE: The distance between the rough opening and
the nished oor/platform must be 3/4”.
3/4”
