15 PB
SPECIFICATIONS
Air Flow Data -7k
Figure 204
Model VRP12K / VRP12R
Air Flow Data
Indoor CFM Low High
.05” ESP
300 360
.10” ESP * 260 325
.15” ESP 230 315
.20” ESP 290
Indoor CFM & External Static Pressure
Maximum ESP on Low Speed = 0.15” w.c.
Maximum ESP on High Speed = 0.20” w.c.
Filter Size: 14” x 20”
Condenser CFM & External Static Pressure
The 7000 BTU VRP
®
is designed to mount through an exterior wall through a plenum (VRAWP*) with an external louver
(VPAL2).
-
tural reasons.
NOTE: If the Friedrich designed plenum and louver combinations are not used, the louver/duct design
must be evaluated by the factory to insure the total pressure drop does not exceed the maximum allow -
able limits.
Condenser External Static Pressure
Design Low Max
CFM
ESP (“WC) ESP (“WC)
550
0.02 0.08
