7k Accessories Dimensional Data-Louvers & Wall-Plenums
10
Accessories Dimensional Data-Louvers & Wall-Plenums
Architectural Louver
VPAL2/VPSC2
25-
9
/
16
”
31-
1
/
16
”
Wall Plenum
VPAWP1-8 - telescopes from 5-
1
/
2
” to 8”
VPAWP1-14 - telescopes from 8” to 14”
A
B
30-
3
/
8
"
24-
1
/
8
"
Figure 209
