PARTS CATALOG
Control Box Diagram
Figure 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80091207 CONTROL BOX LID VRP07 ALL 1
2 80091200 ASSY CONTROL BOX VRP07 ALL 1
3 61670803 TRANSFORMER IN 265V OUT
235V
VRP07RXXXXDX (MODELS WITH 265V) 1
4 62622000 VRP FRIEDRICH MAIN CNTRLLER ALL 1
5 80083543 SD CARD ASSEMBLY FOR THE
MAIN BOARD (FMC)
ALL 1
6 80083432 RELAY, 12VDC COIL X 30A ALL 1
7 62623407 Relay, DPDT 2‑Form C, 12V Coil,
TE T92P11D22‑12
VRP07XXXXSDX (MODELS WITH REHEAT) 1
8 62623403 PCBA, RS‑485 CONVERTER ALL 1
9 62623400 DRIVER, INVERTER 1 TON ALL 1
10 62623402 INDUCTOR‑REACTOR, INVERTER
1 TON
ALL 1
11 62623500 VRP FRIEDRICH HEATER BOARD ALL 1
12 62623401 SUPPLY, DC POWER 12V, 2A, 85‑
265VAC
ALL 1
13 80083723 BLOCK TERM 3 POLES X 6QC
TAB#2‑14
ALL 1
14 25077800 STRAIN RELIEF 30A ALL 1
15 20061450 STRAIN RELIEF 15A AND 2 ALL 1
13 60301805 CLIP DRAIN HOSE ROUTING ALL 1
14 80080005 CABLE GLAND M20 SET ALL 1
15 80080006 CABLE GLAND M25 SET ALL 1
16 80083346 BUSHING SNAP POWER A ALL 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 60‑120 DAYS LEAD TIME
X IN THE USED ON MODEL NUMBER DESIGNATES ALL MODELS FOR THAT DESIGNATION
FOR EXAMPLE VRP07XXXXXDL = ALL VRP 07 MODELS WITH BASEPAN HEAT REFER TO FIGURE 101(MODEL NUMBER
IDENTIFICATION FOR ADDITIONAL DETAILS)
