90 PB
PARTS CATALOG
Control Box Wiring
Figure 903
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 61821438 HARNESS COMPR 32" 14GA SP
3LF
ALL 1
2 80060116 HARNESS INT WALL CTL VRP36 ALL 1
3 80060220 HEATER HARNESS VRP36 ALL 1
4 80082004 HARNESS TWISTED WIRE PWR
TO MAIN VRP07
ALL 1
5 62623404 HARNESS, RS‑485 TO INVERTER ALL 1
6 62623405 HARNESS, POWER SUPPLY TO
LINE
ALL 1
7 62623406 HARNESS, POWER SUPPLY TO
MAIN BOARD
ALL 1
8 80092104 HARNESS, REHEAT AND FRESH
AIR
ALL 1
‑9 80083701 SENSOR EVAP COIL OUT ORG (T5) ALL 1
‑10 80083702 SENSOR RETURN AIR TEMP WHT
(T8)
ALL 1
‑11 80083703 SENSOR EVAP COIL IN GRN (T1) ALL 1
‑12 80083704 SENSOR DISCHARGE AIR YEL (T9) ALL 1
‑13 80083705 SENSOR COMPRESSOR
DISCHARGE BLK (T4)
ALL 1
‑14 80083706 SENSOR COMPRESSOR SUCTION
BLU (T3)
ALL 1
‑15 80083707 SENSOR HEATING LIQUID BRW
(T2)
ALL 1
‑16 80083708 SENSOR COOLING LIQUID ORG
(T6)
ALL 1
‑17 80083709 SENSOR CONDENSER OUT PNK
(T7)
ALL 1
‑18 80083710 SENSOR AMBIENT RED (T10) ALL 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 60‑120 DAYS LEAD TIME
X IN THE USED ON MODEL NUMBER DESIGNATES ALL MODELS FOR THAT DESIGNATION
FOR EXAMPLE VRP07XXXXXDL = ALL VRP 07 MODELS WITH BASEPAN HEAT REFER TO FIGURE 101(MODEL NUMBER
IDENTIFICATION FOR ADDITIONAL DETAILS)
