FRIGOMAT KREAM 2.5 E M04.37389 R.2022.03.30 vi
TAV. 04
N. COD. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNBG DESCRIPCIÓN
1
A01.44069
Telaio Frame Chassis Gestell Bastidor
2
P06.077
Piedino Feet Pied Fuss Pie
3
A03.048
Condensatore ad aria Air Condenser Condenseur à air Luftkondensator Condensador de aire
4
A07.033
Filtro disidratatore Filter Dehydrator Filtre déshydrateur Filtertrockner Filtro secador
5
B01.44163
Compressore
(220-240V 50/60Hz 1ph)
Compressor
(220-240V 50/60Hz 1ph)
Compresseur
(220-240V 50/60Hz 1ph)
Kompressor
(220-240V 50/60Hz 1ph)
Compresor
(220-240V 50/60Hz 1ph)
6
E01.44093
Ventilatore
(230V 50/60Hz 1ph)
Fan
(230V 50/60Hz 1ph)
Ventilateur
(230V 50/60Hz 1ph)
Ventilator
(230V 50/60Hz 1ph)
Ventilador
(230V 50/60Hz 1ph)
7
A04.37897
Supporto ventilatore Fan support Support de ventilateur Fan-Unterstützung Soporte de ventilador
8
A04.44254
Supporto morsettiera Cable Box support
Support de la boîte de
câble
Unterstützung für Kabel-
boxen
Soporte para cajas de
cable
9
E09.44242
Morsettiera Cable Box Boîte de câble Kabelboxen Cajas de cable
10
D06.157
Passacavo Cable grip Passe-câbles Kabelverschraubung Pasa-cable
11
E09.44113
Morsetto Terminal Terminal Klemme Terminal
12
E09.44114
Spina porta fusibile Fuse holder Porte-fusible Sicherungshalter Portafusibles
13
D03.187
Fusibile 5x20 T 0.63A Fuse 5x20 T 0.63A Fusible 5x20 T 0.63A Sicherung 5x20 T 0.63A Fusible 5x20 T 0.63A
14
E08.44269
Fusibile 5x20 T 0.8A Fuse 5x20 T 0.8A Fusible 5x20 T 0.8A Sicherung 5x20 T 0.8A Fusible 5x20 T 0.8A
15
E09.44112
Blocca terminale Terminal Clipfix Bloc terminal Klemmleiste Bloque de terminales
16
E03.37243
Cavo di alimentazione
(220-240V 50/60Hz 1ph)
Power Supply Cord
(220-240V 50/60Hz 1ph)
Câble d'alimentation
(220-240V 50/60Hz 1ph)
Netzkabel
(220-240V 50/60Hz 1ph)
Cable de alimentación
(220-240V 50/60Hz 1ph)
17
E15.44515
Filtro EMC EMC filter Filtre EMC EMC-Filter Filtro EMC
18
E08.43908
Trasformatore Transformer Transformateur Transformator Transformador
19
A04.44077
Supporto scheda elettro-
nica
Main Board Support
Support de la carte élec-
tronique
Unterstützung für elek-
tronische Tafeln
Soporte de placa elec-
trónica
20
E04.41553
Piedino distanziale Spacer for Main Board Support de carte
Befestigungsclip für
Platine
Clip de fijación
21
E15.44260
Scheda di potenza Main Board Carte électronique Elektronische Tafel Placa electrónica
22
B09.066
Perno Pin Pivot Pivot Pivote
23
P10.017
OR 2018 OR 2018 OR 2018 OR 2018 OR 2018
24
A03.37756
Supporto raccogligocce Support for Drip collector Support reciueille gouttes Support Tropfenauffänger Soporte Recogedor gotas
25
P03.053
Raccogligocce Drip collector Recueille - gouttes Tropfenauffänger Recogedor de gotas
