4 | Technology
26 M2320121_en | Installation instructions Pellet boiler PECO
NOTICE
In Germany, the following applies:
r Continuous supply of fuel in the boiler’s ideal output range can be achieved by
using a storage tank with a minimum volume in accordance with 1. BlmSchV. In
this case, no chimney calculations are required in partial load.
4.4 External suction module
B1
H1
H2
L1
1
2
Dimensi
on
Description Unit Size 1 Size 2
L1 Length of suction module mm 220 265
B1 Width of suction module 235 290
H1 Height of suction module 225 235
H2 Total height incl. hose connection 275 285
1 Return-air line connection
(line to suction point)
mm 50
2 Return-air line connection
(line to boiler)
50
