5 | Assembly
28 M2320121_en | Installation instructions Pellet boiler PECO
5.2 Tools required
The following tools are required for assembling the boiler and suction module:
▪ Spanner or box wrench set
▪ Set of Allen keys
▪ Flat head and cross-head screwdrivers
▪ Pipe wrench or water pump pliers (1")
▪ Cordless screwdriver and set of Torx bits (T20, T25, T30)
▪ Power drill with masonry drill bit Ø12 mm
5.3 Transport
The product is delivered on pallet(s) in cardboard packaging.
NOTICE
Possibility of damage to components if handled incorrectly
r Follow the transport instructions on the packaging
r Transport components with care to avoid damage
r Protect components against damp
r Pay attention to the pallet's centre of gravity when lifting
5.4 Positioning
Transport with fork-lift or similar lifting device
r Position a fork-lift or similar lifting device at the pallet and bring in the components
