Assembly | 5
M2320121_en | Installation instructions Pellet boiler PECO 31
5.7 Installing the boiler
5.7.1 Remove boiler from pallet
r Cut through the strapping and lift off the cardboard
r Remove components behind boiler (suction module, furnace tool, etc.) from pallet
Boiler type 15-20:
r Loosen the transport lock on both sides of the boiler
r Lift boiler from pallet
Boiler type 25-35:
r Loosen the transport lock on the back of the boiler
r Lift the boiler and pull the pallet forward
TIP: We recommend using Froling’s KHV 1400 boiler lifting system to make pallet
removal easier
