FREQ OL/TRIP Min
Clearing time for falling below the lower outer grid frequency limit in P**
** P = grid periods; 1 P corresponds to 16.66 ms
FREQ RC Max
"Reconnection"
Upper grid frequency limit for reconnecting to the public grid after disconnection due to an
unacceptable parameter deviation
FREQ RC Min
"Reconnection"
Lower grid frequency limit for reconnecting to the public grid after disconnection due to an
unacceptable parameter deviation
START TIME/INIT
Startup time of the inverter in s
START TIME/RCON
Reconnection time in s after a grid error
AGF
"Advanced Grid Features"
Display range Q MODE / GPIS / GFPR / FULL/LVRT
Q MODE Mode for reactive power specification
- CONST / COSP***
Constant cos phi specification
- CONST / Q REL***
Constant specification of the relative reactive power in %
- CONST / Q ABS***
Constant specification of an absolute reactive power in VA
-COSP (P)
cos phi specification depending on the effective power
-Q (U)
Relative reactive power specification regarding the current
grid voltage
-Q (P)
Relative reactive power specification depending on the ef-
fective power
-OFF
The inverter is operating in the pure effective power range
(cos phi = 1)
GPIS "Gradual Power Increment at Startup"
Soft start function regarding how fast the inverter should in-
crease the power
ON / OFF / N.A.
GFPR "Grid Frequency Depending Power Reduction"
Power reduction depending on the grid frequency
ON / OFF / N.A.
