Fronius Smart Meter TS 5kA-3 - Current Transformer Selection Criteria

3-2E
3-2 (1-3)
3N3E
3N3E
Selection criteria
for current trans-
former
General
Do not use current transformers with a voltage output.
Current transformers are directional. If they are mounted backwards or with swapped
wires, the measured power will be negative.
Primary current
Maximum current per phase. A current converter with a primary current greater than the
20
