Fronius Smart Meter TS 5kA-3 User Manual

Technical data
Technical data Modbus transmission speed: 9600 baud
Parity bit:none
Software version:
- Fronius Datamanager 2.0 (from version 3.16.1 onwards)
- Fronius Symo Hybrid (from version 1.16.1 onwards)
Measuring input
Three-phase nominal voltage
Operating range
400 - 480 V
320 - 552 V (-20% to +15%)
Single-phase nominal voltage
Operating range
230 - 277 V
184 - 318 V (-20% to +15%)
Voltage transformer ratio (kVT) 1 - 1000
e. g. VT 20000/400V kVT = 50
for direct connection: kVT = 1
Self-consumption - voltage path
(max. voltage)
10 VA
Nominal frequency
Tolerance
50 - 60 Hz
45 - 65 Hz
Nominal current, l
b
1 A + 5 A
Maximum current, I
max
6 A
Starting current 10 mA
Current transformer ratio (kCT) 1 - 1000
e. g. TC 800/5A kCT = 160
for direct connection: kCT = 1
Short-time overload
(EN IEC 62053-21, EN IEC 62053-23)
5 l
max
/ 0.5 s
Self-consumption - current path (max. cur-
rent)
0.3 W per phase
Maximum value kVT x kCT 1000 (CT/5A)
Current distortion factor in acc. with EN IEC 62053-21
Power factor
Operating range
(EN IEC 62053-21, EN IEC 62053-23)
active cosφ 0.5 ind - 0.8 cap,
reactive sinφ 0.5 ind - 0.5 cap
Energy
Max. display As per table
Resolution As per table
LED indicator 1 pulse / 0.1 Wh
Active energy accuracy
(EN IEC 62053-21)
Class 1
Reactive energy accuracy
(EN IEC 62053-23)
Class 2
