Fronius Symo 15.0-3-M Installation Instructions

Notes regarding software updates
Notes regarding
software up-
dates
+
3
5 4 4
1
2
2
If the inverter is supplied with a USB
flash drive, the inverter software must
be updated as soon as the inverter has
been commissioned:
1
Plug the USB flash drive into the
data communication area of the in-
verter
2
Open the Setup menu
3
Select the "USB" menu item
4
Select "Software Update"
5
Update the software
43
EN

Fronius Symo 15.0-3-M Specifications

General

Max. efficiency	98.1%
Max. input voltage	1000 V
MPPT voltage range	200 - 800 V
Weight	34.8 kg
Protection rating	IP 66
Max. output current	21.7 A
AC nominal voltage	400 V
AC voltage range	320 - 480 V
Frequency	50 / 60 Hz
THD	< 3%
Number of MPP trackers	2
AC Frequency Range	50 / 60 Hz
Maximum Efficiency	98.1%
Warranty	5 years
AC nominal output	15000 W
Max. apparent AC power	15 kVA
Maximum AC Power	15000 VA
Maximum DC Power	22500 W
Operating Temperature Range	-25 to +60 °C
Max. input current	30 A
Max. input current (Idc max)	30 A
Cooling	Forced air cooling
