Preparation Plug in the mains plug
Move the mains switch to the I position
All the indicators on the control panel light up briefly.
TIG welding Press the Mode button to select the required TIG mode:
Only with MagicWave: Press the Mode button to select the required TIG mode:
Use the left or right parameter selection button to select the relevant welding param-
eters in the welding parameters overview
Use the adjusting dial to set the selected welding parameter to the required value
All welding parameter set values that have been set using the adjusting dial remain
stored until the next time they are changed. This applies even if the power source is
switched off and on again in the meantime.
Open the gas cylinder valve
Set the shielding gas flow rate:
Press the Gas test button
The test gas flow lasts for a maximum of 30 seconds. Press the button again to
stop the gas flow prematurely.
- Turn the adjusting screw on the underside of the pressure regulator until the pres-
sure gauge shows the required gas flow rate
Balance (only on MagicWave for TIG AC welding process)
Unit 1
Setting range -5 to +5
Factory setting 0
-5: highest fusing power, lowest cleaning action
+5: highest cleaning action, lowest fusing power
Electrode diameter
Unit mm in.
Setting range OFF - max. OFF - max.
Factory setting 2,4 0.095
CAUTION! Risk of injury and damage from electric shock. As soon as the mains
switch is in the "I" position, the tungsten electrode of the welding torch is live.
Make sure that the tungsten electrode does not touch any persons or electrically
conductive or earthed parts (e.g. housing, etc.).
1
2
2-step mode
4-step mode
AC welding process
AC welding process with automatic cap-shaping function
DC welding process
1
2
3
4
5
6
