ASSEMBLY
OM 0408SB1184-A
14
Installation of Chute and Manual Rotation Kit 5RDF0016
(Figures 3-4-5-6)
NOTE
: The rotation handle can be installed
on the right or left side of the three point
hitch.
1. Figure 3: Apply grease on the chute base
and around the snowblower chute ring and
install the chute (item 1).
2. Figure 4: Insert the 1 11/16" plastic
bushing (item 1) in the worm support
bracket (item 2) and insert the longest end
of the rotation worm (item 3).
3. Figure 4: Insert the 1 5/16" plastic bushing
(item 4) in the welded tube of the
snowblower (item 5).
4. Figure 4: Place the support (item 2) and
the support spacer (item 10) under the
snowblower's right upper plate (item 6).
5. Figure 3: Install the chute with the four
retaining plates (item 3), four spacers
(item 2), eight 1/2" x 1 1/4" bolts and eight
serrated flange nuts (items 4-5). Tighten
securely.
6. Figure 4: Insert the rotation tube (item 7) in
the worm assembly aligning the holes,
insert an Allen socket head capscrew 10-24
x 1" (item 8) making sure the screw sinks
into the rotation worm and secure with a
nylon insert nut (item 9).
7. Figure 5: Install the rotation bracket
(item 1) on the left or right arm of the three
point hitch with two 3/8" NC x 1 1/4" bolts,
lockwashers and nuts (items 2-3-4). Tighten
firmly.
8. Figure 5: Attach the handle support
bracket (item 5) to the rotation bracket
(item 1) with a 3/4"NC x 1 1/4" bolt,
lockwasher and nut (items 6-7-8) making
sure to attach the brackets in the direction
illustrated.
9. Figure 5: Insert the handle support (item 9)
in the bracket (item 5) adjusting the height
of the support according to your needs and
secure in place with a 3/8" x 1/2" square
head setscrew (item 10).
10. Figure 5: Insert the grommet (item 11) in
the handle support (item 9).
11. Figure 6: Insert the handle (item 1) in the
handle support (item 4) and in the rotation
tube. Select desired length, align nearest
holes and secure with the 4 mm x 80mm
hairpin (item 2). Install the plastic handle
(item 3).
12. Figure 5: Once the snowblower is attached
to the tractor, adjust handle position and
height to ensure comfort and safe
operation. Tighten setscrew (item 10) on
the handle support as well as the 3/4" x
1 1/2" bolt, 3/4" lockwasher and 3/4" nut
(items 6-7-8).
13. Figure 6: To insure the manual rotation
functions properly, position the handle
support (item 4) the closest possible to the
top link mounting point of the three point
hitch while making sure it does not come
into contact with the operator's seat when
the snowblower is fully raised.
14. Tighten all bolts according to the Torque
Specification Table at the end of the
manual.
CAUTION
To avoid personal injury, check the full lifting
range of the snowblower, to ensure that the
chute rotation handle is clear of the
operator’s area when the snowblower is in
raised position.
