Frontier SB1184 - 5 RDF0016 - Manual Rotation

PARTS
OM 0408SB1184-A
45
5RDF0016 - MANUAL ROTATION
R
EF. DESCRIPTION QTY PART #
1 Handle 1 5RD664902
2 Rotation tube 1 5RD660188
3 Handle su
pp
ort 1 5RD660187
4 Handle su
pp
ort b
r
acke
t
1 5RD660269
5 Rotation worm 1 5RD659161
6 Worm su
pp
ort bracket for SB1148-SB1154 & SB1164 1 5RD659145
7 Bracke
t
1 5RD660388
8 Plastic handle 1 5RD656797
9 Plastic
g
romme
t
1 5RD657390
10 Plastic bushin
g
1 5/16" 1 5RD657335
11 Plastic bushin
g
1 11/16" 1 5RD657336
12 Hair
p
in 4mm x 80mm 1 5RD1800002
13 Bolt hex. 3/8"NC x 1 1/4" PTD 2 5RD0100039
14
A
llen socket head ca
p
screw 10-24 x 1" PTD 1 5RD0800009
15 S
q
uare head setscrew 3/8" x 1/2" PTD 1 5RD0600006
16 Nut hex. 3/8" NC PTD 2 5RD0900003
17 N
y
lon insert locknut 10-24 PTD 1 5RD1000002
18 Lockwasher 3/8" PTD 2 5RD1200004
19 Bolt hex. 3/4"NC x 1 1/2" PTD 1 5RD0100115
20 Nut hex. 3/4" NC PTD 1 5RD0900008
21 Lockwasher 3/4" PTD 1 5RD1200008
22 Roll
p
in 1/4" x 1 1/4" l
g
PTD 2 5RD1600015
23 Universal bloc
k
1 5RD658193
24 Rotation
y
oke 1 5RD659595
25 Worm su
pp
ort bracket
(
for SB1174 & SB1184 onl
y)
1 5RD668477
26 S
p
ace
r
1 5RD668092
