SPECIFICATIONS
OM 0408SB1184-A
3
* With manual rotation
Features and Specifications SB1184 SB1194
Working Width 84" 94"
Transport Width 84" 94"
Working Height 34" 34"
Length 55 3/8" 55 3/8"
Single/Dual Auger Single Single
Auger Diameter 20" 20"
Auger Flighting Thickness 3/8" 3/8"
Impeller Diameter 27 1/2" 27 1/2"
Impeller Width 10 1/2" 10 1/2"
Impeller Shaft Diameter 40 mm (1 9/16") 40 mm (1 9/16")
Number of Impeller blades 4 4
Roller Chain 60H 60H
Drive sprocket (# of teeth) 12 12
Driven sprocket (# of teeth) 32 32
Chain idler Manual adjustment Manual adjustment
Gearbox Manufacturer Comer Comer
Gearbox Description Model T-27D Model T-27D
Tractor RPM 540 540
Impeller RPM 540 540
Auger RPM 200 200
PTO Manufacturer Comer Comer
PTO Description 50 60
Skid Shoe Adjustable Adjustable
Skid Shoe Material High carbon steel High carbon steel
End Plate Thickness 3/16" 3/16"
Back Plate Thickness 11ga 11ga
Impeller Housing Thickness 11ga 11ga
Impeller Blade Thickness 3/8" 3/8"
Side Panel Bottom Thickness 3/16" 3/16"
Cutting Edge Welded Welded
Cutting Edge Dimension 1/2" x 3" 1/2" x 3"
Chute Base Standard Standard
Parking Stand Standard Standard
Hitch Category Cat. 1 & 2 Cat. 2 only
Quick Hitch Compatibility
ASABE Compatible
Cat. 1 & 2
ASABE Compatible
Cat. 2 only
HP Requirements - min-max (hp) 35-90 35-90
Operating Weight (lbs)-hyd. rot. & defl. 1130 1182
Shipping Weight (lbs) 1060 1021
Approx. Set-up Time (min.) * 35 35
Chute Deflector Adjustment (standard) Manual Manual
Chute Deflector Adjustment (option)
Hydraulic - cylinder (2"x8") including
hoses and tips
Electric – 8" actuator - 1000 lbs.
including hardware, switch, and
electric cable.
Hydraulic - cylinder (2"x8") including
hoses and tips
Electric – 8" actuator - 1000 lbs.
including hardware, switch, and
electric cable.
Chute Rotation
Manual - worm gear w/ handle.
Hydraulic - cylinder (2"x8") including
bracket, hoses, and tips
Manual - worm gear w/ handle.
Hydraulic - cylinder (2"x8") including
bracket, hoses, and tips
Chute
Two-part Two-part
