PARTS
OM 0408SB1184-A
42
GEARBOX 5RD662195 FOR SB1184 & SB1194
REF. DESCRIPTION QTY
PART #
1 Casing 1 5RD656640
2 Seal kit 35 x 72 x 10 1 5RD659845
3 External retaining ring 1 5RD656652
4 Spacer 2 5RD656649
5 Bearing flange 1 5RD659844
6 Spacer 1 5RD656648
7 Internal retaining ring 1 5RD656654
8 Bearing flange 1 5RD656647
9 Shaft 1 5RD656651
10 Gear 1 5RD656645
11 External retaining ring 1 5RD656646
12 Bearing flange 2 5RD656641
13 Spacer 1 5RD656644
14 Internal retaining ring 2 5RD656642
15 Seal kit 40 x 80 x 12 2 5RD656643
16 Shaft 1 5RD662212
17 Gear 1 5RD656657
18 Spacer 1 5RD661146
19 Plug 1 5RD656662
20 Cover 1 5RD656660
21 Bolt hex. M10 x 14 gr.8.8 4 5RD656659
22 Plug 3/8" NPT 2 5RD655259
