PARTS
OM 0408SB1184-A
41
SNOWBLOWER – SB1184 & SB1194
R
EF. DESCRIPTION QTY PART #
39 Bushing 1.5 OD x 2 1/8" lg PTD 2 5RD668603
40 Bushing 1 1/2" lg x 3 3/8" lg PTD 2 5RD668553
41 Linchpin 7/16" PTD 3 5RD1900003
42 Hitch pin 7/8" x 6 1/4" lg Cat. 1 2 5RD4600043
43 Chain #60H x 94 links, w/connecting link 1 5RD655788
44 Connecting link #60H
1
5RD662029
45 Spacer ring 656"ID x 1.760 x 1" ext. 1 5RD668093
46 Idler sprocket 60A12 1 5RD3300022
47 Spacer ring .656"ID x 1.151 lg x 1" ext. 1 5RD668094
48 Bolt hex. 5/16"NC x 3/4" lg gr.5 PTD 1 5RD0100018
49 Bolt carriage 5/8" NC x 1 1/2" lg gr.5 PTD 4 5RD0300043
50 Left adjustable skid shoe 1 5RD666287
51 Right adjustable skid shoe 1 5RD666288
52 Flange bearing 1 1/4" hole, 4 holes 3 5RD4300001
53 Lockwasher 1/2" PTD 20 5RD1200006
54 Nut hex. 1/2" NC PTD 12 5RD0900006
55 Nylon flat washer 11/32" hole 2 5RD658467
56 Sprocket 60A32 1 5RD654167
57 Nut hex 3/8" NC gr.5 PTD 8 5RD0900003
58 Bolt hex. 1/2" NC x 1 1/2" lg gr.5 PTD 12 5RD0100070
59 Bolt hex. 5/8" NC x 5" lg gr.5 PTD 1 5RD0100105
60 Flat washer 5/8" (11/16" dia. hole) 2 5RD1400008
61 Lockwasher 5/8" PTD 1 5RD1200007
62 Nut hex. 5/8" NC gr.5 PTD 1 5RD0900007
63 Bolt hex. 3/8" NC x 3/4" lg gr.5 PTD 4 5RD0100037
64 Spacer 4 5RD668549
65 Driving shaft – SB1184 1 5RD669621
Driving shaft – SB1194 1 5RD669622
66 Eyebolt 3/8" NC x 4" lg inc. nut 1 5RD0400027
67 Nut hex. 5/8" NC PTD 4 5RD0900007
68 Lockwasher 3/8" PTD 8 5RD1200004
69 Hitch pin 1 1/8" x 6 1/4" lg Cat. 2 2 5RD4600042
70 Hitch pin 3/4" x 5 7/16" lg Cat. 1 1 5RD4600051
71 Gearbox 1 5RD662195
72 Auger – SB1184 1 5RD666278
Auger – SB1194 1 5RD666290
