FrontRow CM3000

2
LAN
Speaker cable
Cat5e/6 cable
Audio cable
CB65
CM3000
Conductor Head End Installation
Shuttle Touch Screen PC
*Use with stereo to mono 3.5mm adapter (included)
CMP500
RJ11 phone line
LAN1
LAN1
Intercom
Audio Streaming Out (optional)
SPKR
DRS5000
To phone system
Audio Streaming In
Installed as part of a Conductor Admin Station, it may look like this:
Conductor Head End Installation
