8-3
8.2.1 Backs, Panels, Doors, Handles, Sides, Tilt Housings & Top Caps
ITEM PART # COMPONENT
1 230-0675 Back Panel, Upper Single FPRE117/122
230-0676 Back Panel, Upper 2-Station FPRE217/222
2 230-0672 Back Panel, Center Single FPRE117/122
230-0673 Back Panel, Center 2-Station FPRE217/222
3 106-5016 Frame, Control Panel, Single FPRE117/122
106-5221 Frame, Control Panel, 2-Station FPRE217/222
4 823-5567 Tilt Housing, Single FPRE117/122
823-5484 Tilt Housing, 2-Station FPRE217
823-6398 Tilt Housing, 2-Station FPRE222
5 106-5195 Top Cap, Single FPRE117/122
106-5196 Top Cap, 2-Station FPRE217/222
* 200-9614 Heat Shield, Single FPRE117/122
* 200-9610 Heat Shield, 2-Station FPRE217/222
6 106-4979 Door Assembly Single FPRE117/122 (includes items below plus 210-9214)
* 210-9213 Panel, Door Universal Single FPRE117/122
* 210-9215 Liner, Door Universal Single FPRE117/122
* 809-0500 Screw, #10 – ½ Hex TR HD SS
* 826-1343 Spring, Door Pin Hinge Single FPRE117/122 and FPRE217/222
(Pkg. of 10)
106-4769
Door, Left or Right 2-Station FPRE217/222 (Left shown – move handle to
opposite side for Right)
7 809-0500 Screw, #10 X ½-inch Hex Head FPRE217/222
8 210-9214 Handle, Door
9 106-4067SP Pin Assembly, Door FPRE117/122, FPRE217/222
10 231-1588 Side, Cabinet Left, Single FPRE117/122
231-0326 Side, Cabinet Left, 2-Station FPRE217/222
232-1588 Side, Cabinet Right, Single FPRE117/122
232-0326 Side, Cabinet Right, 2-Station FPRE217/222
11 810-1105 Magnet, Door
12 210-9086 Door Tab
* 809-0123 Screw, #10 –3/4 Truss Slotted Head
* 826-1376 Nut KEPS 10-32 HX ZP (Pkg. of 10)
* 210-9188 Hinge, Door Single FPRE117/122
* 809-0970 Retaining Ring – Door Hinge Pin
13 823-5656 Cove, Element Tilt Housing
14 210-5623 Bezel, Insert for Remote Single-Controller
15 210-9085 Bezel, Insert for Remote Double-Controller
* Not illustrated.
