Frymaster FPRE117 - Terminal Blocks

8-14
8.4.3 Terminal Blocks
ITEM PART # COMPONENT
1 823-5631 Box, LH Rear Terminal Block
2 823-5632 Box, RH Rear Terminal Block
3 220-0801 Cover, Rear Terminal Block Box
4 807-3970 Block, 3 Pole 600V 175A
5 807-0070 Terminal, Ground Lug
6 807-0128 Bushing, Insulating Heyco
7 809-0247 Nut, #8-32 Hex
8 809-0250 Nut, #6-32 Hex
9 826-1363 Screw, #8-32 x ½ Hex Head (Pkg. of 25)
10 826-1374 Screw, #10 – ½” Hex Head (Pkg. of 25)
