8.4.6.3 Contactor Box Wiring Assemblies – 9-Pin (Right Element)
8.4.6.4 Main Wiring Harness
8.4.6.5 Component Box and Filter Pump Wiring Harnesses
1
2
ITEM PART # COMPONENT
1 106-5750 Full Vat Control Harness J4 to J2 (WIR0765 required with this harness)
2 106-5935 Filter Pump C2 to Component Box Wiring Harness
P/N 807-4077
Blue Mate-N-Lock Moisture Seals are sold separately and can be found on page 8-26.
