8-7
8.2.2.2 FPRE217/222 Double Station Fryer
ITEM PART # COMPONENT
106-4919 Cabinet Assembly, FPRE Electric Double S/S
1 106-4946 Upright Assembly, Right
2 106-4947 Upright Assembly, Left
3 106-4767 Base Assembly, FPRE Double Electric
4 210-8978 Support, Right Filter Pan
5 210-8979 Support, Left Filter Pan
6 210-8984 Support, Cross Cabinet
7 210-8986 Divider, Cabinet
8 210-8987 Brace, Front Horizontal Two-Station Fryer
9 210-8989 Brace, Rear Horizontal Two-Station Fryer
10 210-9116 Shield, Channel
11 231-0326 Side, Left Cabinet
12 231-0811 Bracket, RE LH Contactor Box Mounting Station 1
13 232-0326 Side, Right Cabinet
14 232-0811 Bracket, RE RH Contactor Box Mounting Station 2
15 826-1389 Screw, Hex Head ¼”-20x ¾” (Pkg. of 10)
16 809-0190 Washer, Flat ¼” SS
17 809-0191 Washer, ¼” Lock Spring
18 826-1376 Nut, 10-32 Keps Hex (Pkg. of 10)
19 826-1374 Screw, #10x ½-inch Hex Washer Head (Pkg. of 25)
20 809-0417 Nut, ¼” -20 Hex Flange
21 809-0429 Bolt, ¼”-20 x 2-inch Hex Head
22 824-1488 Bracket, Rear Support
23 823-5241 Leg, Marine Shipboard (Mounts with Items 20 and 21)
24 210-9033 Hinge, Door
25 210-8993 Brace, Rear Channel Corner
26 809-0500 Screw, #10 X ½-inch Hex Washer Head SS
27 823-5105 Channel, Base Rear Two-Station Fryer
28 823-5106 Channel, Base Side
29 810-2346 Magnet, Door
30 210-9023 Bracket, Frypot
31 823-5313 Filter Pan Stop
* 809-0782 Washer, 5/16 SS Flat
* 810-0783 Cotter Pin
* Not illustrated.
