8-13
8.4.2 Contactor Boxes cont.
ITEM PART # COMPONENT
1 106-8789 Box Assembly, FPRE Left Contactor
2 106-8790 Box Assembly, FPRE Right Contactor
3 106-8982 Box Assembly, Single Foot Print Contactor
4 807-0331 Transformer, 480V/120V 150VA
5 807-2284 Contactor, 24V 50 Amp Mechanical
6 810-1202 Contactor, 24V 40 Amp Mechanical
7 807-2434 Relay, Shunt 24V Coil 18 Amp
8 807-1683 Relay, Power 12 VDC
9 807-0012 Relay, Tilt 18 Amp ⅓ HP 24V Coil
10
807-0922
Holder, Bus Fuse
11
807-2278
Fuse, 20 Amp
12 231-1135 Cover, RE Left Hand
13 232-1135 Cover, RE Right Hand
14 230-4012 Cover, RE Single Foot Print
* 231-0811 Bracket, Left Hand Contactor Box Mounting RE
* 232-0811 Bracket, Right Hand Contactor Box Mounting RE
* WIR0751 Wire Assembly, Filter Shunt Relay
* WIR0726 Wire Assembly, Hood Relay
* WIR0712 Wire Assembly, Latch and Hood Relay
** Not illustrated.
