8-5
8.2.2.1 FPRE117/122 Single
ITEM PART # COMPONENT
106-6452 Cabinet Assembly Single Footprint Marine
1 106-4947 Upright Assembly, Enclosure Left
2 106-4946 Upright Assembly, Enclosure Right
3 106-6457 Support Assembly, Left
4 106-6458 Support Assembly, Right
5 230-1502 Brace, Single Rear Horizontal
6 230-1503 Brace, Single Front Horizontal
7 230-1510 Channel, Left Side
8 230-1509 Channel, Right Side
9 230-1505 Support, Cabinet Cross
10 230-1515 Brace, Contactor Box Locking
11 231-1588 Side, Cabinet Left
12 232-1588 Side, Cabinet Right
13 823-5877 Leg
14 823-5589 Channel, Rear Cabinet
15 824-1716 Bridge, Pump/Motor
16 823-5313 Filter Pan Stop
* 809-0782 Washer, 5/16 SS Flat
* 810-0783 Cotter Pin
* 826-1362 Nut, ¼-20 Hex (Pkg. of 10)
* 809-0191 Washer, ¼ Lock Spring ZP
* 809-0500 Screw, #10 - ½ Hex Head SS
* 809-0417 Nut, Flange ¼ - 20
* 809-0508 Bolt, 14 – 20 x 1 ¼ AT HX HD SS
* Not illustrated.
